8′ (96″) DIAMETER EXHAUST FAN
- Lower Energy Consumption
- Lower Maintenance Cost
- Longer Life Span
- 100,000 CFM – 125,000 CFM
- 7.5HP and 10HP Motors
THE BEAST ADVANTAGE
- Lightweight, Fiber-reinforced composite blade
- Vibrates less and runs smoother
- Quiet operation
- Static pressures up to .4″
- Industrial-grade components
- Low maintenance
- Remote greasing during fan operation
Design Features Reduce Livestock Stress
| Benefit | Design Feature |
|---|---|
| INCREASED DURABILITY & AIR FLOW | Fiber-reinforced composite blades |
| MAXIMUM EFFICIENCY | Lightweight dense foam core |
| STRUCTURAL INTEGRITY | Galvanized heavy walled rectangular steel frame |
| STRENGTH & LONGEVITY | Double walled ribbed fiberglass shroud |
| REDUCED VIBRATION & NOISE | Airfoil design & heavy gauge frame |
| EASE OF MAINTENANCE | Remote grease fittings, Easy-access safety guards & quick change belts |
| REDUCED DUST COLLECTION | Anti-static coating |
PLUS
- Able to operate at higher static pressures
- Applicable to tunnel vent & cross vent barns
- Complete integrated cooling systems available
- Louvers available
- Sizes from 7 ft to 24 ft
- Automation and Control options available
96″ – 12-BLADE CONFIGURATION
Ask Agpro how to optimize the BEAST for your project!
| MOTOR HP | MOTOR AMPS | PHASE | DRIVE | RPM | CFM | CFM/WATT |
|---|---|---|---|---|---|---|
| 7.5 | 7.83 | three | belt | 304 | 101700 | 21.82 |
| 10 | 10.8 | three | belt | 314 | 116000 | 17.99 |
